3D bioprinted silk fibroin hydrogels for tissue engineering

Soon Hee Kim, Heesun Hong, Olatunji Ajiteru, Md. Tipu Sultan, Young Jin Lee, Ji Seung Lee, Ok Joo Lee, Hanna Lee, Hae Sang Park, Kyu Young Choi, Joong Seob Lee, Hyung Woo Ju, In-Sun Hong, Chan Hum Park

Published: 2021-10-28 DOI: 10.1038/s41596-021-00622-1

tissue engineering

silk fibroin hydrogels

3D bioprinting

methacrylated bioink

biocompatibility

AI 解读

Fabrication of angstrom-scale two-dimensional channels for mass transport

Efficient and strand-specific profiling of replicating chromatin with enrichment and sequencing of protein-associated nascent DNA in mammalian cells

The eINTACT method for studying nuclear changes in host plant cells targeted by bacterial effectors in native infection contexts

Rapid reaction optimization by robust and economical quantitative benchtop19F NMR spectroscopy

Profiling native pulmonary basement membrane stiffness using atomic force microscopy

Photoimmunotechnology as a powerful biological tool for molecular-based elimination of target cells and microbes, including bacteria, fungi and viruses

Measuring key human carbohydrate digestive enzyme activities using high-performance anion-exchange chromatography with pulsed amperometric detection

Neural cell isolation from adult macaques for high-throughput analyses and neurosphere cultures

Preparation, validation and use of a vasoactive tryptophan-derived hydroperoxide and relevant control compounds

Neuronal subtype-specific growth cone and soma purification from mammalian CNS via fractionation and fluorescent sorting for subcellular analyses and spatial mapping of local transcriptomes and proteomes

查看全部

Sections

Figures

References

The development of biocompatible and precisely printable bioink addresses the growing demand for three-dimensional (3D) bioprinting applications in the field of tissue engineering. We developed a methacrylated photocurable silk fibroin (SF) bioink for dig
Introduction
Materials for Procedure 1
Procedure 1: fabrication of Sil-MA bioink and hydrogel and characterization
Materials for Procedure 2
Procedure 2: trachea tissue engineering using Sil-MA hydrogel
Troubleshooting
Timing
Anticipated results
References
